Hikrobot MV-CA013-20GM GigE Mono Camera

The Hikrobot MV-CA013-20GM is a cost-effective yet powerful Gigabit Ethernet industrial camera designed for entry-level to mid-range machine-vision tasks. Built around the ON Semiconductor PYTHON1300 global-shutter CMOS sensor, it offers 1.3 megapixels at an impressive 90 frames per second. With a standard 29 mm x 29 mm x 42 mm form factor, C-mount lens compatibility, and Power-over-Ethernet convenience, this camera delivers exceptional value for Canadian SMEs launching automated inspection and robotics projects. Hikrobot's MVS client software and SDK support Windows and Linux environments with full GigE Vision V2.0 and GenICam compatibility, while the 128 MB onboard buffer ensures reliable image capture even under high network load.

Key Specifications:

• Sensor: ON Semi PYTHON1300 global shutter CMOS
• Resolution: 1280 x 1024 pixels (1.3 MP)
• Frame Rate: 90 fps at full resolution
• Pixel Size: 4.8 —m x 4.8 —m
• Interface: GigEwith Fast Ethernet
• Lens Mount: C-Mount
• Dimensions: 29 x 29 x 42 mm
• Power: 12 VDC or PoE, typical 2.7 W
• Compliance: GigE Vision V2.0, GenICam, CE, FCC, RoHS

Use Cases:

• High-speed conveyor belt inspection in food processing
• Compact vision systems for electronics assembly
• Barcode and DPM code reading in warehousing
• Robotic guidance for parts sorting and handling
• Educational and R&D prototyping in Canadian universities

Why Source from Dark AI Factories:

• Canada-wide shipping with fast delivery to Toronto, Vancouver, Montreal, Calgary, and beyond.
• Bilingual FR/EN support — our team serves you in English or French for seamless procurement.
• Expert curation — every camera is vetted by machine-vision specialists for reliability and performance.
• Local stock Canadt documentation for hassle-free integration.
• Dedicated technical pre-sales support to help you choose the right sensor, lens, and interface.

Integration & Software Ecosystem:

Hikrobot's MVS client software and SDK support Windows and Linux environments with full GigE Vision V2.0 and GenICam compatibility. The camera integrates effortlessly with HALCON, VisionPro, and LabVIEW, while the 128 MB onboard buffer ensures reliable image capture even under high network load. PoE support reduces cabling complexity, and the compact 29 mm form factor allows dense multi-camera arrangements. Dark AI Factories offers Canadian customers local technical onboarding, sample capture scripts in C++ and Python, and guidance on triggering modes for high-speed synchronization.

What's Included:

• Hikrobot MV-CA013-20GM camera body
• C-mount lens mount (lens sold separately)
• 6-pin Hirose I/O connector
• GigE patch cable (optional)
• MVS software download link and quick-start guide

Warranty & Support from DAF:

Every camera purchased through Dark AI Factories comes with our commitment to long-term partnership. We provide datasheet access, sample code repositories, integration guides, and direct manufacturer escalation when needed. For Canadian customers, we offer localized invoicing, bilingual documentation packages, and post-sales engineering support to ensure your vision system performs flawlessly from day one. Whether you are a startup in Waterloo's robotics corridor, a research lab in Montreal, or an oil-and-gas operator in Alberta, Dark AI Factories is your trusted imaging partner.
