Intel RealSense D405 Short-Range Camera

The Intel RealSense Depth Camera D405 is purpose-built for close-range computer vision tasks where sub-millimeter precision is paramount. Optimized for an operating range of 7 cm to 50 cm, the D405 uses high-resolution global-shutter depth sensors with active IR stereo technology to detect objects as small as 500 microns at 7 cm distance. Its uniquely compact 42 x 42 x 23 mm form factor and lightweight 72-gram design make it the perfect depth sensor for mounting on robot wrists, end-effectors, and compact inspection heads. Canadian manufacturers in precision assembly, medical device production, and delicate agricultural handling rely on the D405 for trustworthy automated inspections and gentle robotic manipulation. Intel RealSense SDK 2.0 provides comprehensive APIs for depth alignment, point-cloud generation, and spatial mapping.

Key Specifications:

• Depth Technology: Active IR stereo (short-range optimized)
• Depth Resolution: 848 x 480 @ up to 90 fps
• RGB Resolution: 1920 x 1080 global shutter
• Optimal Range: 7 cm to 50 cm
• Minimum Object Detection: 500 —m at 7 cm
• Precision: —2% at 25 cm
• Field of View: 87— x 58—
• Interface: USB-C (USB 3.2 Gen 1)
• Dimensions: 42 x 42 x 23 mm
• Weight: 72 g
• SDK: Intel RealSense SDK 2.0, ROS/ROS2

Use Cases:

• Robotic gripping and pick-and-place for small electronic components
• Medical wound assessment and 3D skin topology mapping
• Precision assembly line defect detection down to 0.1 mm
• Gentle produce handling and soft-robotics agriculture
• Dental scanning and small-object 3D measurement

Why Source from Dark AI Factories:

• Canada-wide shipping with fast delivery to Toronto, Vancouver, Montreal, Calgary, and beyond.
• Bilingual FR/EN support — our team serves you in > Expert curation — every camera is vetted by machine-vision specialists for reliability and performance.
• Local stock planning and Canadian-compliant documentation for hassle-free integration.
• Dedicated technical pre-sales support to help you choose the right sensor, lens, and interface.

Integration & Software Ecosystem:

Intel RealSense SDK 2.0 provides comprehensive APIs for depth alignment, point-cloud generation, and spatial mapping, with built-in support for ROS, ROS2, OpenCV, and PCL. The D405's compact square form factor (42 mm) is optimized for mounting on robot wrists and cobot end-effectors, and its global-shutter RGB sensor eliminates rolling-shutter artifacts during fast motion. Active IR projection ensures reliable depth acquisition even on low-texture surfaces common in manufacturing. Dark AI Factories offers Canadian automation integrators robot-mounting bracket designs, cable strain-relief acces, and sample picplace code for Universal Robots and FANUC systems.

What's Included:

• Intel RealSense D405 depth camera module
• USB-C cable
• Mounting bracket with M3 holes
• Protective lens cover
• SDK 2.0 access, ROS node, and UR integration sample

Warranty & Support from DAF:

Every camera purchased through Dark AI Factories comes with our commitment to long-term partnership. We provide datasheet access, sample code repositories, integration guides, and direct manufacturer escalation when needed. For Canadian customers, we offer localized invoicing, bilingual documentation packages, and post-sales engineering support to ensure your vision system performs flawlessly from day one. Whether you are a startup in Waterloo's robotics corridor, a research lab in Montreal, or an oil-and-gas operator in Alberta, Dark AI Factories is your trusted imaging partner.
