Shining3D EinScan Pro HD Scanner

The EinScan Pro HD by Shining3D raises the bar for professional handheld 3D scanning. Using advanced structured-light technology, it captures geometry at 0.045 mm accuracy with rich color texture, making it equally suited to reverse-engineering legacy parts, creating digital archives of cultural artifacts, and conducting first-article inspection. Modular turntable and color-camera attachments expand capability as project demands grow.

Key Specifications:

• Accuracy: up to 0.045 mm
• Scan speed: 1,500,000 points/s (handheld rapid)
• Point distance: 0.2—3 mm (adjustable)
• Working distance: 310 mm
• Align modes: feature, marker, turntable, texture
• Color texture capture (with Color Pack)

Applications:

Education: College design and manufacturing programs teaching reverse engineering, metrology, and digital-shape acquisition.

Research: Archaeology and palgitization, biomechanics body-scanning, and custom-medical-device shape capture.

Industry: Automotive aftermarket part replication, aerospace MRO (maintenance, repair, overhaul), plastic-injection mold verification, and heritage-preservation documentation.

Consumer: Advanced makers and prop designers seeking professional-grade digitization for 3D-printing workflows.

What is in the Box:

• EinScan Pro HD handheld scanner unit
• Power adapter & cable
• Calibration board
• Marker set (for marker alignment)
• Carrying case
• USB 3.0 cable
• Quick-start guide & ExScan Pro software license (bilingual FR/EN)
