xTool S1 Enclosed Laser

The xTool S1 brings enclosed-laser safety to the desktop diode market. With a fully interlocked Class 1 safety enclosure, it is the machine we recommend first for schools, libraries, and shared makerspaces where student and operator safety is non-negotiable.

Inside the sleek white cabinet, the S1 houses a 20W or 40W diode module with a generous 498 — 319 mm work area and an integrated rotary attachment for cylinders and spheres. The built-in camera preview, auto-focus, and passthrough slot for long materials make it as productive as it is safe.

Key Specifications:

• Laser Type: Diode (20W or 40W options)
• Working Area: 498 —" —ï")
• Max Cutting Depth: Up to 8 mm wood (20W), 12 mm acrylic (40W)
• Precision: 0.01 mm
• Safety Rating: Laser Class 1 (fully enclosed with interlocks)
• Rotary: Built-in rotary attachment included
• Camera: Wide-angle camera for preview and positioning
• Connectivity: USB, Wi-Fi
• Software: xTool Creative Space, LightBurn compatible
• Ventilation: Built-in exhaust fan with hose port

Applications:

Education: The S1 is purpose-built for K-12 and post-secondary classrooms. Its Class 1 enclosure means no additional laser-safety officer certification is required in most Canadian jurisdictions, removing a major barrier to adoption. Students can engrave stainless-steel drink bottles, acrylic awards, and wooden plaques safely.

Makers & Hobbyists: Home users who want the power of an open-frame laser without the noise, smell, and safety concerns will appreciate the integrated fume extraction and quiet operation. The rotary handles wine glasses, baseball bats, and curved phone grips out of the box.

Small Business: Trophy shops, gift stores, and personalization services benefit from the S1—s clean, retail-friendly appearance. It looks professional on a counter and operates quietly enough for a retail floor.

Prototyping: The passthrough slot allows cutting and engraving on long boards and acrylic sheets, making it suitable for architectural model parts, signage prototypes, and packaging mockups.

What is in the Box:

• xTool S1 enclosed laser unit
• 20W or 40W laser module (selected)
• Built-in rotary attachment
• Exhaust hose and clamp
• Laser safety goggles (backup pair)
• Power cable and USB cable
• xTool Creative Space software (download)
• Quick-start guide and material test cards
